μεταχειρισμενα Icom IC-2AT

Διαβάστε παρακαλώ ΚΑΙ τις πληροφορίες του προφίλ μου.


SPECIFICATIONS
GENERAL
Type: Amateur VHF transceiver
Frequency range: TX: 144-148 MHz
RX: 144-148 MHz
Tuning steps: 5 / 10 / 100 KHz, 1 MHz
Frequency stability: Max ? ppm
Mode: FM
Channels/memory management: None
Repeater shift/offset: ±600 KHz
Power supply: 8.4 VDC
Current drain/power consumption: RX: 20-130 mA
TX: 220-550 mA
Antenna impedance/connector: 50 ohm / BNC
Dimensions (W*H*D): 65*117*35 mm (2.56*4.61*1.38"), without battery pack
Weight: 490 g (17.28 oz), with BP3
Other features:

RECEIVER SECTION
Receiver system: Double conversion superheterodyne
1st IF: 10.695 MHz
2nd IF: 455 KHz
Sensitivity: 0.5 uV (20 dB noise quieting)
Selectivity: 15 KHz (-6 dB)
30 KHz (-60 dB)
Image rejection:
AF output power/speaker: 300 mW at ?% distortion / 8 ohm
External speaker connector:

TRANSMITTER SECTION
RF output power:

High Low
2 m: 1.5 W 150 mW
Modulation system: Variable reactance frequency modulation
FM deviation: ±5 KHz
Spurious emissions: Less than -60 dB
Microphone impedance/connector: ? ohm / ?-pin
Microphone input sensitivity: ? mV

MISCELLANEOUS
Manufactured: Japan, 19xx-19xx (Discontinued)
